HORNO PARA CERAMICA, VIDRIO, METALES – CON VENTANA – 24.92 LITROS

PARTE: 2PA-TNFJ141 - HORNO PARA CERAMICA, VIDRIO, METALES – CON VENTANA – 24.92 LITROS

Nuevo con garantía

Temperatura Máxima 926 grados centígrados

2400 Watts, 20 Amps,

Medidas interiores: ancho 330 mm x fondo 330 mm x alto 229 mm

OPCIONES:

120V, 1 fase

240V, 1 fase

Furniture kit

The digital TnF-J-14-1 is popular for heating jewelry molds. Made of ceramic fiber for fast heating and cooling. The digital controller yields consistent quality jewelry molds. It is a real time-saver. Set the controller and spend your time working on jewelry instead of monitoring the kiln. The TnF-J-14-1 operates on 120 volts. Maximum temperature is 1700° F.

The firing chamber is a one-piece ceramic fiber shell with embedded elements. For greater thermal efficiency, the space between the steel case and the ceramic fiber shell is filled with extra ceramic fiber insulation.

The TnF-J-14 comes with a vent hole and steel cover in the top and door. The door seals tightly with a heavy spring latch. The controls, located in the base, stay cool for long life. No extra stand is needed.

The TnF-J-14-1 is available with an optional wax tray for lost wax casting.

You will be amazed at the convenience of digital firing. The reliable solid-state Sentry controller continually monitors the firing so you can spend your time productively without closely watching the kiln. (Please remember, however, to check the kiln during firing and to monitor it near the expected shutoff time.) The sealed touch pad keeps out dust and is easy to wipe clean.

The controller has powerful features that you will enjoy using. Yet we have also worked hard to make the controller user-friendly.

Do you ever wonder how much electricity your kiln uses? The digital controller can figure this for you with the press of a button. Find out how little a kiln actually costs to fire. Learn to conserve energy by experimenting with firing speed, load density, etc.

Thermocouple with “special limit” wire

The thermocouple senses temperature inside the kiln. It is the small rod that extends into the firing chamber. The ¼” wide Type-K, 14-gauge, exposed-tip thermocouple is made with special-limit wire for superior accuracy. The exposed tip gives the controller a fast response time for even temperatures during holds. The thermocouple is made in America to our exacting standards.

Designed for production

Paragon’s warranty is not affected by frequency of use. Fire your new kiln every day if you want, even in commercial settings. That will have no effect on the warranty period.

Optional colors at no extra charge

Brighten your studio with color! Order your kiln in one of our standard colors at no extra charge . . . berry, black, blue, hot pink, jade, navy, purple, or turquoise. Scroll down to see color samples in the options section.

Max. Temperature: 1700F = 926C

Amps: 20

Phase: 1

Watts: 2400

Nema: 5-20R

TUV tested to CSA and UL Standard 499: N

CE: N

Control Type: Sentry Digital 12-key Non-Ceramic

Voltage: 120

Hertz: 60

Kiln Type: Front Loading Square

Sides: 4

Chamber Volume: 0.88 CU.FT. = 24.92 litres

Chamber Width: 13.00 IN = 330 mm

Chamber Depth: 13.00 IN = 330 mm

Chamber Height: 9.00 IN = 229 mm

Outer Size: 18.00W x 21.50D x 20.50H Inches = 457W x 546D x 521H mm

Ship Size: 26.50W x 28.50D x 28.50H Inches = 673W x 724D x 724H mm

Ship Weight: 110.00 Lbs. = 49.90 Kg.
