Identificador: 1939
Abierta
Descripción
PARTE: 12381 - CNC TALADRO, ENGOMA, INSERTA – WEEKE
USADA – MUY BUENAS CONDICIONES
Year 2013
Model Optimat ABD-050
Year 2013
460 volt three phase, 60 hz, 10 amps
(1) horizontal CNC controlled X-axis drilling head
0.55 kw drill head drive motor
Spindle speed 7500 rpm
Max tool length 70 mm (2.75")
(1) glue injector with dowel insertion head
Top mounted vibrating dowel hopper feeder
Pneumatic actuation of drill head stroke and dowel insertion head
(2) independent table work zones (can be used together for full working width)
Max working width (both zones) 1260 mm (49.6")
Max working width (single zone) 620 mm (24.4")
Min working width 50 mm (1.96")
Workpiece thickness range 10 mm to 60 mm (0.39" to 2.36")
Dowel capacity 8 mm dia. X 30 mm length or 8 mm dia. X 35 mm length
Foot pedal table zone clamp controls
(4) top adjustable width pneumatic stock clamps
89" wide x 20" long machine work table size
36" table work height
Front mounted operator computer control station
17" color display screen with keyboard and mouse
Beckhoff computer C9900-1374 V1.1
Intel Core 2 Duo CPU T7400 @2.16Ghz
1.99 GB of RAM
Microsoft Windows Xp operating system
Hand held bar code scanner
Weeke machine software
Includes machine manual
Pago y Devoluciones
- Forma de pago
- Transferencia/Deposito Bancario
Publicar mensaje
Ingresar to ask the seller a question.
AMXmachinery
COMPRESOR DE TORNILLO - 50 HP - INGERSOLLRAND
PARTE: 12061 - COMPRESOR DE TORNILLO - 50 HP - INGERSOLLRANDMgf: 2006212 ACFM @ 125psiRemanufactured Airend with only 600 hours on it(95,000 Total Hours on unit)Annual PM performed 600 hours ago460 volt Aircooled Unit / Original Motor30-day Full Package Warranty
AMXmachinery
PARTE: AMX-10140 - EXTRACTORES CENTRIFUGO - MOTOR 1.5 HP, 230V, 1 FASE
PARTE: AMX-10140 - EXTRACTORES CENTRIFUGO - MOTOR 1.5 HP,
230V, 1 FASE
7 PIEZAS EN EXISTENCIAS
USADO - BUENAS CONDICIONES
MEDIDAS: 11.5” ANCHO X 14.5” FONDO
X 14” ALTO
MOTOR 1.5 HP, 230V, 1 FASE (1.1 KW),
CERRADO
ENTRADA REDONDA: 5.5”
SALIDA RECTANGULAR: 5” X 4.5”
HECHOS EN EUROPA
AMXmachinery
PARTE: 12573 - TALADRO MULTIPLE - ALTA PRODUCCION - RILESA - UNI-X 2200 MM
PARTE: 12573 - TALADRO MULTIPLE - ALTA PRODUCCION -
RILESA - UNI-X 2200 MM
USADO - MUY BUENAS CONDICIONESPLC
Control System with 15” Color TFT Touch-screen DisplayPneumatic
magazine with ergonomic and user-friendly accessEnd
Mounted Horizontal Drilling Groups: 2 @ 1.1kW(1.5HP) 3-5000RPMRear
Mounted Horizontal Drilling Groups: 4 @ 1.1kW(1.5HP) 4000RPMTop
Mounted Vertical Drilling Groups: 6 @ 1.1kW(1.5HP) 4000RPMPneumatic
side movement of drill groups for copy function of holesBackstop...
AMXmachinery
CNC DRILL GLUE INSERT DOWEL MACHINE OMAL VELOX 1300
PART: 12062E – CNC DRILL – GLUE – INSERT – DOWEL MACHINE - OMAL VELOX 1300USED – IN VERY GOOD CONDITIONSIN MINT SHAPEMFG 2014 BUT WAS SOLD NEW JAN 2016YEAR 2014INCLUDES LASER PART SENSOR2 ZONE MACHINE WITH 51" WORKING AREAA LASER SENSOR AUTOMATICALLY MEASURES THE WIDTH OF A PANEL AND CALCULATED THE POSITION AND NUMBER OF DOWELS BASED ON A PROGRAM FILETESTED VIDEO 1:https://vimeo.com/438240935
