Descripción
DOBLADORA DE METAL 8' X 10 GA PARTE: 2GM-0810E
- Taiwan machines
- All (3) rolls are hardened rolls, up to 50-52 HRC
- 3-rollers are driven to perform high accuracy
- Adjustable cone attachment included
- 3/8”, ½” and 5/8” grooves on rollers
- One wheel one-side operated for bending roll
- One wheel one-site operated for pinch roll (E model is powered)
- Heavy duty casting frame
- Heavy duty all steel welded construction
- 1/3 of full length in middle of roller is straight, and two ends with crown to get perfect round performance.
- Quiet running operation
- Easy swing-out top roller
- Safety line all around the machine for emergency stop
- All rolls run forward and reverse
- Safety type forward/reverse foot pedal
- Power source 220V, (option: 440V, 3 phase)
- Adjustable cone attachment
- 3/8”, ½” and 5/8” grooves on rollers
- All (3) hardened rolls
- Removable safety foot pedal
- Operation & parts manual
- Orange color front cover is optional.
- E models come with motorized bending roll up/down w/ push button and digital display for easy operation of repeat jobs
Capacity: Mild Steel Stainless Steel soft aluminum min. thickness |
8'2" x 10Ga. 8'2" x 14Ga. 8'2" x 1/4" 26Ga.
|
|
|
| Roll Dia. | 6" |
| Min. Bending Dia. Inch | 8" |
| Pre-bend inch | 0.12" |
| Rolls Speed ft/min | 17 |
| Rolls Opening | 1/2" |
| Main Motor | 4HP 3PH 220V or440V |
| Weight | 4,550 lbs. |
| Overal Dimensions | 132" x 35" x 56" |
