DOBLADORA DE METAL 5' X 10GA

AMXmachinery1

Contact Seller

Description

DOBLADORA DE METAL 5' X 10GA PARTE: 2GM-0510E

This machine has a 3HP Motor, rated at 220V three phase. Power bending roll up/down with push button & display.

SO 9001 certifiedTaiwan machinesAll (3) rolls are hardened rolls, up to 50-52 HRC3-rollers are driven to perform high accuracyAdjustable cone attachment included3/8”, ½” and 5/8” grooves on rollersOne wheel one-side operated for bending rollOne wheel one-site operated for pinch roll (E model is powered)Heavy duty casting frameHeavy duty all steel welded construction1/3 of full length in middle of roller is straight, and two ends with crown to get perfect round performance.Quiet running operationEasy swing-out top rollerSafety line all around the machine for emergency stopAll rolls run forward and reverseSafety type forward/reverse foot pedalPower source 220V, (option: 440V, 3 phase)Adjustable cone attachment3/8”, ½” and 5/8” grooves on rollersAll (3) hardened rollsRemovable safety foot pedalOperation & parts manualOrange color front cover is optional.E models come with motorized bending roll up/down w/ push button and digital display for easy operation of repeat jobs

Capacity: Mild Steel Stainless Steel soft aluminum min. thickness	5'1" x 10Ga. 5'1" x14Ga. 5'1" x 1/4" 26Ga

Roll Dia.	4 3/4"
Min. Bending Dia. Inch	6"
Pre-bend inch	0.12"
Rolls Speed ft/min	20
Rolls Opening	1/2"
Main Motor	3HP 3PH 220V or 440V
Weight	3,050 lbs.
Overal Dimensions	96" x 32" x 52"
