Description
PARTE: 2MK-PHM.30 - BASTIDORA DE UNIONES - 1HP
Is engineered for professionals seeking efficiency and precision in production work. With a simple tap of the foot pedal, this durable machine clamps the stock, routes a pocket, and drills a pilot hole seamlessly.
Designed with a perfect 4º pocket angle, it creates the strongest wood joints for a variety of projects. Powered by a robust 2.25HP Bosch Router and a 1HP Bosch Drill Router, delivers all the power you need to tackle even the most demanding tasks. Ideal for cabinetry, furniture making, and more, this pocket hole machine enhances your workflow and elevates the quality of your craftsmanship.
| Technical Information | |
|---|---|
| Driver Bit Angled | 4° Angle |
| Power | 1PH -127 v |
| Height | 42.5" |
| Router | Bosch 2.25 Hp 16 amp |
| Drill Router | Bosch 1.0 Hp 12 amp |
| Router Bit | 3/8” bit 1/4’’ shank 2 |
| Drill Bit | 1/8” – 2 3/4” |
| Wood Thickness Limit | 1/2” – 1-9/16” |
| Adjustable Fence | Yes |
| Dust Port | 4’’ |
| Air Pressure | 85 psi |
| Footprint | 25” x 30” x 42 1/2" |
| Laser Guide | Yes |
| Speed Control | Yes |
| Dual Sided Top | Yes – Smooth & Textured |
| Depth Gauge | Yes – MM & Inches |
| Weight | 174 Lbs |
